Sealed, reliable solid state internals. 12 volt. Requires separate earth connection to pump body via fixing bolt.

Less than 2 amp current drain.

Will self prime up to 0.6 mtr lift.

Footprint 140mm x 82mm x 85mm high (without unions).

2 bolt fixing at 65mm centres.

Removable, washable internal nylon filter.

Weight 760gm.

Operating temperature range -60 to +43 deg C.

Will pump from 4.5 psi to 5.5 psi.

Flow rate 113 ltrs/hour (30 US gal/hr.)

Union thread size 1/8" npt female. PIPE UNIONS NOT INCLUDED

IMPORTANT NOTE: ALL FUEL PUMPS MUST BE FITTED WITH A PRE-FILTER ON THE INLET SIDE. RETURNED PUMPS WILL NOT BE REPLACED OR REFUNDED IF FOUND DAMAGED DUE TO DEBRIS.

FACET SILVER TOP  ROAD CYLINDRICAL SOLID STATE PUMP #FAC6
